Description

Braided sheath is intended to used to establish working channel for a variety of minimally invasive procedures. The stainless-steel braided reinforcement is designed to enhance the stability, strength, kink resistance and pushability performance.

Application

-Angiography catheters
-Electrophysiology catheters
-Delivery catheters
-Stent catheters
-Steering mechanism assemblies
-PTA/PTCA guiding catheters
-High- pressure injection lines
-Kink resistant sheaths

Features

01

Outstanding kink resistant sheath with stainless steel braid reinforcement for complex and tortuous anatomy
02

High column strength sheath designed for stent delivery system, occludes and other devices
03

The ultra-smooth liner facilitates the placement of instruments
04

Excellent steerablity with 1:1 torque at the proximal and distal ends
05

Super trackability with radiopaque band maker to facilitates the placement of the sheath tip under X-ray

Specification

Outer Diameter

2F-30F
Single Wall Thickness

0.005"(0.13mm) - 0.038"(0.97mm)
Max. Length

2600mm
Outer Layer

Nylon, Pebax and custom blends
Liner

Pebax, PTFE, Radiopaque blends, custom liners
Wire Material

304 Stainless Steel
Wire Pattern

Max. PPI 250
Wire Size

Flat: 0.0005" x 0.003"-0.002" x 0.007” / Round: 0.001” - 0.004"
Tensile Strength

As specification by customer
Braided Patterns

Regular Braid Pattern/Diamond Braid Pattern/Half Load
Value-added Capabilities

Thermal tip stem bonding/ Insert molding/ Tip bonding/ Drilling
